Multi Cylinder Four Stroke Petrol Engine Test Rig

Multi Cylinder Four Stroke Petrol Engine Test Rig
Multi Cylinder Four Stroke Petrol Engine Test Rig
Send Inquiry
Product Code : 1683
Brand Name : Ambros
Product Description

Multi Cylinder Four Stroke Petrol Engine Test Rig



DESCRIPTION:-

The Set-up consists of 3/4 Cylinder, 4 Stroke Petrol Engine connected to Dynamometer for engine loading. The Setup has stand-alone type independent panel box consisting of air box, fuel tank, and manometer, fuel measuring unit, digital speed indicator and digital temperature indicator. Engine Jacket cooling water Inlet, Outlet and Calorimeter Temperature is displayed on temperature indicator. Rotameters are provided for cooling water and Calorimeter Flow measurement.



FEATURES:-

  • Compact Set-up
  • Non contact Digital Speed Measurement
  • Morse Test



RANGE OF EXPERIMENTS: Study of engine performance for power, efficiencies, fuel consumption, air fuel ratio and heat balance. Morse Test



UTILITIES REQUIRED:-

  • Electric Supply: - Provide 230 +/- 10 VAC, 50 Hz, Single Phase Electric Supply with proper earthing. (Neutral – Earth voltage less than 5 VAC)
  • Space: - 3500L x 4400W x 2000H in mm Foundation as per drawing supplied.
  • Water Supply: Continuous clean and soft water supply @ 4000 LPH, Head 10 m. (min), Connection 1” BSP with Tap/valve.
  • Drain: - Provide drainpipe 2 ½” NB size.
  • Exhaust: - Provide exhaust pipe 1 ½ “NB size.
  • Fuel, Oil: Petrol:  10 Ltrs, Lubricating Oil:3.5 Ltrs (20W40)



SPECIFICATIONS: -

Product

Engine Test Set-up 3/4 Cylinder, 4 Stroke, Petrol

Engine

Refurbished Engine, Make – Maruti 800,3 Cylinder, 4 Stroke Petrol, BHP 37 at 3600RPM, Capacity 796 CC, Torque 59, @ 2500RPM, Water Cooled, Without T/M, (Carburetor)

Dynamometer

Type Rope with set of Weights

Type Electrical with Loading Device

Type Hydraulic with Loading Device

Type Eddy Current with Loading Device

Air Box

M S Fabricated with Orifice Meter and Manometer

Fuel Tank

Capacity 15 Ltrs. With Glass Fuel Metering Column

Calorimeter

Type Pipe in Pipe

Speed Indicator

Digital with Non Contact type Speed Sensor

Temperature

Type Digital. Multipoint, Input K type

Indicator

Thermocouple

Temperature Sensor

Thermocouple, Type K

Fuel Flow

Fuel Measuring unit, Range 0-450 ml

Air Flow

Manometer, Range 100 – 0 – 100 mm

Rotameter

Engine cooling : 100 – 1000 lph,

Calorimeter : 40 – 400 lph

Overall Dimensions

  W 2000 x D 2750 x H 1750 mm

A good quality painted rigid MS Structure is provided to support all the parts.
