Reciprocating Pump Test Rig

Reciprocating Pump Test Rig

1000-800000 INR/Unit

Product Details:

  • Product Type Pump Test Rig
  • Dimension (L*W*H) 1500 x 1000 x 80 mm Millimeter (mm)
  • Equipment Materials SS
  • Voltage 220-380 Volt (v)
  • Warranty 1 Year
  • Click to View more
X

Reciprocating Pump Test Rig Price And Quantity

  • 100000.00 - 800000.00 INR/Unit
  • 1000-800000 INR/Unit
  • 1 Unit

Reciprocating Pump Test Rig Product Specifications

  • SS
  • 220-380 Volt (v)
  • 1500 x 1000 x 80 mm Millimeter (mm)
  • Pump Test Rig
  • 1 Year

Reciprocating Pump Test Rig Trade Information

  • 10 Unit Per Day
  • 15-30 Days
  • All India

Product Description

We are a renowned manufacturer, exporter and supplier of Reciprocating Pump Test Rig. The offered rig is manufactured under the observation of our diligent professionals using excellent quality components with the aid of modern techniques. This rig is commonly used to measure the efficiency of reciprocating pump. Our quality experts also check this rig on certain quality aspects to ensure its proper functioning. Besides, we are providing this Reciprocating Pump Test Rig in various specifications at cost effective prices.


Features:

  • Rust resistance tank
  • Strong painted structure
  • Easy to operate and maintain
  • Equipped with closed water loop

EXPERIMENT:-

  • To determine overall efficiency and pump efficiency of the Reciprocating Pump
  • To plot Head vs. Discharge, Pump efficiency vs. Discharge

FEATURES:-

  • Closed loop water circulation
  • Compact & stand alone set-up
  • MS Excel sample calculation program on demand
  • Stainless Steel tanks and watted parts
  • Superb painted structure
  • Simple to Operate & Maintain

UTILITIES REQUIRED:-

Electric Supply: - Provide 230 +/- 10 VAC, 50 Hz, Single Phase Electric Supply with proper earthing. (Neutral - Earth voltage less than 5 VAC) 5 A, three pin socket with switch for pump.

Water Supply: Tap water connection½" BSP., Distilled water @ 80 Ltrs. (Optional extra cost)

TECHNICAL SPECIFICATIONS: -

  • Pump : Double acting, single Cylinder, Capacity 1 HP Speed 250 RPM (max.), Head 5 Kg/cm2 (max.)
  • Drive : AC Motor with step cone pulley arrangement for 3 prefixed speed Or DC Motor with DC Drive along with non-contact type Digital RPM Indicator
  • Supply Tank : Capacity 70 Ltrs.
  • Measuring Tank : Capacity 50 Ltrs. fitted with Piezometer Tube & Scale
  • Piping : GI / PVC
  • Stop Watch : Electronic
  • Control Panel : With required electrical instrumentation
The whole Set-up is well designed and arranged in a good quality painted structure.
