GEAR PUMP TEST SETUP

GEAR PUMP TEST SETUP
GEAR PUMP TEST SETUP
Send Inquiry
Product Code : 1355
Brand Name : Ambros
Product Description

Being a customer oriented enterprise, we are affianced in manufacturing, exporting and supplying GEAR PUMP TEST SETUP. Designed to work on on three phase electric supply, the offered set up is widely used to determine the overall efficiency of gear pump. In order to manufacture this set up, our dexterous professionals use high quality components and innovative techniques. Apart from this, the provided GEAR PUMP TEST SETUP can be bought from us in different technical specifications at reasonable prices.




Features:

  • Compact and standalone set-up
  • Rust free pipes
  • Accurate reading
  • Digital RPM Indicator



EXPERIMENT:-

  • To determine overall efficiency and pump efficiency of the Gear Pump
  • To plot Head vs. Discharge, Pump efficiency vs. Discharge



FEATURES:-

  • Closed loop water circulation
  • Compact & stand alone set-up
  • MS Excel sample calculation program on demand
  • Stainless Steel tanks and wetted parts
  • Superb painted structure
  • Simple to Operate & Maintain



UTILITIES REQUIRED:-

  • Electric Supply: - Provide 230 +/- 10 VAC, 50 Hz, Single Phase Electric Supply with proper earthing. (Neutral - Earth voltage less than 5 VAC) 5 A, three pin socket with switch for pump.
  • Oil Supply: Oil @ 30 Ltrs. (Optional extra cost)



TECHNICALS SPECIFICATIONS: -

  • Pump : Gear Pump with pair of meshed gears Capacity 1 HP, Speed 1500 RPM (max.), Head 5 Kg/cm2 (max.)
  • Drive : AC Motor with step cone pulley arrangement for 3 prefixed speed
  •            DC Motor with DC Drive along with non-contact type Digital RPM Indicator
  • Supply Tank : Capacity 30 Ltrs.
  • Measuring Tank : Capacity 20 Ltrs. fitted with Piezometer Tube & Scale
  • Piping : GI / PVC
  • Stop Watch : Electronic
  • Control Panel : With required electrical instrumentation

The whole Set-up is well designed and arranged in a good quality painted structure.
